UF stand-alone bag filter is the small size bag filter with the advanced technology level of 1990s. it can be used singly or assembled with many together ( mechanical shaking type). It is mainly used for dust filtering of the top silo, bottom silo, top bin and all kinds of output deveices. When the filters are used in assembly, they are mainly used in small size mills, crushers and other continuous dust filtering. Woven terylene cloth is used for the combining bags. The inlet temperature is lower than 120℃ and the inlet density is 100g/m3N. The outlet discharging density is lower than 100mg/m3N. We can also provide abrasion resistant and temperature resistant material bag filter with stainless steel or aluminium structure if you have special request, 2500Pa pressure resistant cabinet structure is used in UF stand-alone bag filter. There is unique shaking dust removing facility with advanced manual and automatic electric control devices.
Compared to other stand-alone bag filters, UF stand-alone bag filter(dust remover) is characterized by small volume, tight structure, high efficiency, low energy consumption, long using life, easy installation and easy maintenance(internal filtering). It is economical and pratical. It is an ideal small bag filter(dust remover).
Technical parameter of UF stans-alone bag filter
|
|
2
|
3
|
4
|
5
|
6
|
7
|
|
|
Handle volume(m3/h)
|
The max.
|
1360
|
2720
|
4080
|
5450
|
6800
|
8160
|
|
Rated
|
1020
|
2040
|
3060
|
4080
|
5100
|
6120
|
|
|
Total filtering area(m2)
|
18.6
|
37.2
|
55.7
|
74.3
|
92.9
|
111.5
|
|
|
Quantity of filter bag
|
8
|
16
|
24
|
32
|
40
|
48
|
|
|
Type of motor for fan
|
Y90S-2
|
Y112M-2
|
Y132S1-2
|
Y132S1-2
|
|||
|
Motor power of fan(KW)
|
1.5
|
2.2
|
4.0
|
5.5
|
5.5
|
7.5
|
|
|
Vibrated motor power(KW)
|
0.55
|
0.55
|
0.55
|
0.75
|
0.75
|
0.75
|
|
|
Motor power of dust discharge valve(KW)
|
0.55
|
0.55
|
0.55
|
0.55
|
0.55
|
0.55
|
|
|
Assemble type
|
FM、STD、FB
|
FM、STD
|
|||||
