application
Nantong China-Mining SLVds -0.1 manual single, double flat gate valves are widely used in building material, metallurgy, mining and other industries dust material flow control of piping. The material flow is to control dust ideal equipments.
Second, characteristics
SLVds -0.1 manual single, double flat gate simple structure, light weight, flexible operation, raplace singly, adopt high quality carbon steel manufacturing, high strength, good performance and long service life etc. SLVds -0.1 manual single, double flat gate screw and nuts are the soft shield structure, not by external dust influence.
Three, working principle
Nantong middlings SLVds -0.1 manual single, double flat gate mainly by the framework, screw nut, the handwheel, wheel, sluice composition, the handwheel (sprocket) rotation, screw with screw nut and disc for horizontal reciprocating motion, reach the valve opening and closing purpose.
Four, model establishment instructions
Five, the main property parameter
|
Nominal pressure
|
Suitable temperature
|
Suitable media
|
|
0.1-0.6MPa
|
≤150℃
|
Dust material
|
Six, appearance and connecting size
